Watec WAT-202D Industrial Color CCD Video Camera

Ryfutone Co., LTD
Contact Now

Watec WAT-202D Industrial Color CCD Video Camera

Place of Origin : japan

Brand Name : watec

Model Number : WAT-202D

Delivery Time : 3days

Payment Terms : T/T or PAYPAL

MOQ : 1pcs

Contact Now

The Watec WAT-202D is one of the smallest and lightest CCTV box cameras available on the market. This makes it all the more surprising that the manufacturer was able to incorporate into its tiny frame most of the features and functions found on larger and heavier cameras. These include a 1/3" CCD sensor, an auto iris function as well as a full complement of electronic controls. Working in concert, these allow the camera to produce visible images in light levels down to 1.0 lux. This degree of low light sensitivity coupled with its incredibly small size makes it the camera of choice for residential or commercial applications looking for dependable yet minimally intrusive round-the-clock security monitoring.
The WATEC WAT-202D high resolution low light solution color camera is utilized in the Medical Imaging, Military, and Law Enforcement Industries. The Watec WAT-202D's capability to adhere to five different light temperature ranges makes it adaptable to nearly every environment.


Ultra Compact & Lightweight Body
With a total length of only 2.7" and weighing less than 7 ounces, this is one of the smallest and lightest full featured CCTV box cameras available on the market.

User Selectable Shutter Speed & White Balance Settings
Two knob-type dials on the back of the camera allow a user to select the appropriate color temperature and exposure levels to suit a particular lighting environment.

Watec WAT-202D Features:

* 1/3" CCD
* 450 Lines
* 1.0 Lux
* Auto Iris
* Ultra Compact & Lightweight
* Selectable White Balance
* Selectable Shutter Speed

Watec WAT-202D Specifications:

ModelWAT-202D
image sensor1/3" CCD
Sensing area(pixel)P440K
Synchronizing SystemInternal Synchronization
Scanning system2:1
video output1Vpp-75Ω
Resolution (horizontal)450Lines
Minimum illumination1.0Lux F1.2(AGC High)
Gain controlAutomatic gain control (dB) ON=8~36 (Hl) 8~24 (LO) OFF=8
S/N ratio46dB
Gray propertiesγ≒0.45/1.0
BLCON/OFF
AES EI:OFF1/50~1/100,000 sec.
EI:FL 1/120~1/100,000 sec.
MES(S)OFF(1/50),1/250,1/500,1/1000,1/2000,1/4000,1/10,000
WBAUTO/Fixed /3200K,4200K,5100K,6300K
Auto Iris LensVIDEO/DC
MountCS
Working VoltageDC+10V~15V
working current (mA)150
Storage Temperature (℃ )-30~+70
Operating Temperature (℃ )-10~+40
Size W×H×L(mm)43.5×44×64.5
Weight(G)150

Watec WAT-202D Industrial Color CCD Video Camera













Product Tags:

watec color camera



watec ccd camera



ccd video camera


Quality Watec WAT-202D Industrial Color CCD Video Camera for sale

Watec WAT-202D Industrial Color CCD Video Camera Images
